fastjet 2.4.5
|
|
fastjet 2.4.5
|
Class that behaves essentially like ClusterSequence except that it also provides access to the area of a jet (which will be a random quantity... More...
#include <ClusterSequenceActiveAreaExplicitGhosts.hh>
Public Member Functions | |
| template<class L > | |
| ClusterSequenceActiveAreaExplicitGhosts (const std::vector< L > &pseudojets, const JetDefinition &jet_def, const GhostedAreaSpec &ghost_spec, const bool &writeout_combinations=false) | |
| constructor using a GhostedAreaSpec to specify how the area is to be measured | |
| template<class L > | |
| ClusterSequenceActiveAreaExplicitGhosts (const std::vector< L > &pseudojets, const JetDefinition &jet_def, const std::vector< L > &ghosts, double ghost_area, const bool &writeout_combinations=false) | |
| template<class L > | |
| void | _initialise (const std::vector< L > &pseudojets, const JetDefinition &jet_def, const GhostedAreaSpec *ghost_spec, const std::vector< L > *ghosts, double ghost_area, const bool &writeout_combinations) |
| does the actual work of initialisation | |
| unsigned int | n_hard_particles () const |
| returns the number of hard particles (i.e. those supplied by the user). | |
| virtual double | area (const PseudoJet &jet) const |
| returns the area of a jet | |
| virtual PseudoJet | area_4vector (const PseudoJet &jet) const |
| returns a four vector corresponding to the sum (E-scheme) of the ghost four-vectors composing the jet area, normalised such that for a small contiguous area the p_t of the extended_area jet is equal to area of the jet. | |
| virtual bool | is_pure_ghost (const PseudoJet &jet) const |
| true if a jet is made exclusively of ghosts | |
| bool | is_pure_ghost (int history_index) const |
| true if the entry in the history index corresponds to a ghost; if hist_ix does not correspond to an actual particle (i.e. | |
| virtual bool | has_explicit_ghosts () const |
| this class does have explicit ghosts | |
| virtual double | empty_area (const RangeDefinition &range) const |
| return the total area, up to |y|<maxrap, that consists of unclustered ghosts | |
| double | total_area () const |
| returns the total area under study | |
| double | max_ghost_perp2 () const |
| returns the largest squared transverse momentum among all ghosts | |
| bool | has_dangerous_particles () const |
| returns true if there are any particles whose transverse momentum if so low that there's a risk of the ghosts having modified the clustering sequence | |
Private Member Functions | |
| void | _add_ghosts (const GhostedAreaSpec &ghost_spec) |
| adds the "ghost" momenta, which will be used to estimate the jet area | |
| template<class L > | |
| void | _add_ghosts (const std::vector< L > &ghosts, double ghost_area) |
| another way of adding ghosts | |
| void | _post_process () |
| routine to be called after the processing is done so as to establish summary information on all the jets (areas, whether pure ghost, etc.) | |
Private Attributes | |
| int | _n_ghosts |
| get the area of the ghosts | |
| double | _ghost_area |
| std::vector< bool > | _is_pure_ghost |
| std::vector< double > | _areas |
| std::vector< PseudoJet > | _area_4vectors |
| double | _max_ghost_perp2 |
| bool | _has_dangerous_particles |
| unsigned int | _initial_hard_n |
Static Private Attributes | |
| static LimitedWarning | _warnings |
| handle warning messages | |
Class that behaves essentially like ClusterSequence except that it also provides access to the area of a jet (which will be a random quantity...
Figure out what to do about seeds later...)
Definition at line 49 of file ClusterSequenceActiveAreaExplicitGhosts.hh.
| fastjet::ClusterSequenceActiveAreaExplicitGhosts::ClusterSequenceActiveAreaExplicitGhosts | ( | const std::vector< L > & | pseudojets, |
| const JetDefinition & | jet_def, | ||
| const GhostedAreaSpec & | ghost_spec, | ||
| const bool & | writeout_combinations = false |
||
| ) | [inline] |
constructor using a GhostedAreaSpec to specify how the area is to be measured
Definition at line 55 of file ClusterSequenceActiveAreaExplicitGhosts.hh.
: ClusterSequenceAreaBase() { std::vector<L> * ghosts = NULL; _initialise(pseudojets,jet_def,&ghost_spec,ghosts,0.0, writeout_combinations); }
| fastjet::ClusterSequenceActiveAreaExplicitGhosts::ClusterSequenceActiveAreaExplicitGhosts | ( | const std::vector< L > & | pseudojets, |
| const JetDefinition & | jet_def, | ||
| const std::vector< L > & | ghosts, | ||
| double | ghost_area, | ||
| const bool & | writeout_combinations = false |
||
| ) | [inline] |
Definition at line 65 of file ClusterSequenceActiveAreaExplicitGhosts.hh.
: ClusterSequenceAreaBase() { const GhostedAreaSpec * ghost_spec = NULL; _initialise(pseudojets,jet_def,ghost_spec,&ghosts,ghost_area, writeout_combinations); }
| void fastjet::ClustSeqActAreaEG::_add_ghosts | ( | const GhostedAreaSpec & | ghost_spec | ) | [private] |
adds the "ghost" momenta, which will be used to estimate the jet area
Definition at line 46 of file ClusterSequenceActiveAreaExplicitGhosts.cc.
References fastjet::GhostedAreaSpec::actual_ghost_area(), fastjet::GhostedAreaSpec::add_ghosts(), and fastjet::GhostedAreaSpec::n_ghosts().
{
// add the ghosts to the jets
ghost_spec.add_ghosts(_jets);
// now add labelling...
for (unsigned i = _initial_hard_n; i < _jets.size(); i++) {
//_jets[i].set_user_index(1);
_is_pure_ghost.push_back(true);
}
// and record some info from the ghost_spec
_ghost_area = ghost_spec.actual_ghost_area();
_n_ghosts = ghost_spec.n_ghosts();
}
| void fastjet::ClusterSequenceActiveAreaExplicitGhosts::_add_ghosts | ( | const std::vector< L > & | ghosts, |
| double | ghost_area | ||
| ) | [private] |
another way of adding ghosts
add an explicitly specified bunch of ghosts
Definition at line 222 of file ClusterSequenceActiveAreaExplicitGhosts.hh.
{
for (unsigned i = 0; i < ghosts.size(); i++) {
_is_pure_ghost.push_back(true);
_jets.push_back(ghosts[i]);
}
// and record some info about ghosts
_ghost_area = ghost_area;
_n_ghosts = ghosts.size();
}
| void fastjet::ClusterSequenceActiveAreaExplicitGhosts::_initialise | ( | const std::vector< L > & | pseudojets, |
| const JetDefinition & | jet_def, | ||
| const GhostedAreaSpec * | ghost_spec, | ||
| const std::vector< L > * | ghosts, | ||
| double | ghost_area, | ||
| const bool & | writeout_combinations | ||
| ) |
does the actual work of initialisation
Definition at line 169 of file ClusterSequenceActiveAreaExplicitGhosts.hh.
{
// don't reserve space yet -- will be done below
// insert initial jets this way so that any type L that can be
// converted to a pseudojet will work fine (basically PseudoJet
// and any type that has [] subscript access to the momentum
// components, such as CLHEP HepLorentzVector).
for (unsigned int i = 0; i < pseudojets.size(); i++) {
PseudoJet mom(pseudojets[i]);
//mom.set_user_index(0); // for user's particles (user index now lost...)
_jets.push_back(mom);
_is_pure_ghost.push_back(false);
}
_initial_hard_n = _jets.size();
if (ghost_spec != NULL) {
_add_ghosts(*ghost_spec);
} else {
_add_ghosts(*ghosts, ghost_area);
}
if (writeout_combinations) {
std::cout << "# Printing particles including ghosts\n";
for (unsigned j = 0; j < _jets.size(); j++) {
printf("%5u %20.13f %20.13f %20.13e\n",
j,_jets[j].rap(),_jets[j].phi_02pi(),_jets[j].kt2());
}
std::cout << "# Finished printing particles including ghosts\n";
}
// this will ensure that we can still point to jets without
// difficulties arising!
_jets.reserve(_jets.size()*2);
// run the clustering
_initialise_and_run(jet_def,writeout_combinations);
// set up all other information
_post_process();
}
| void fastjet::ClustSeqActAreaEG::_post_process | ( | ) | [private] |
routine to be called after the processing is done so as to establish summary information on all the jets (areas, whether pure ghost, etc.)
Definition at line 110 of file ClusterSequenceActiveAreaExplicitGhosts.cc.
{
// first check for danger signals.
// Establish largest ghost transverse momentum
_max_ghost_perp2 = 0.0;
for (int i = 0; i < _initial_n; i++) {
if (_is_pure_ghost[i] && _jets[i].perp2() > _max_ghost_perp2)
_max_ghost_perp2 = _jets[i].perp2();
}
// now find out if any of the particles are close to danger
double danger_ratio = numeric_limits<double>::epsilon();
danger_ratio = danger_ratio * danger_ratio;
_has_dangerous_particles = false;
for (int i = 0; i < _initial_n; i++) {
if (!_is_pure_ghost[i] &&
danger_ratio * _jets[i].perp2() <= _max_ghost_perp2) {
_has_dangerous_particles = true;
break;
}
}
if (_has_dangerous_particles) _warnings.warn("ClusterSequenceActiveAreaExplicitGhosts: \n ghosts not sufficiently soft wrt some of the input particles\n a common cause is (unphysical?) input particles with pt=0 but finite rapidity");
// sort out sizes
_areas.resize(_history.size());
_area_4vectors.resize(_history.size());
_is_pure_ghost.resize(_history.size());
// First set up areas for the initial particles (ghost=_ghost_area,
// real particles = 0); recall that _initial_n here is the number of
// particles including ghosts
for (int i = 0; i < _initial_n; i++) {
if (_is_pure_ghost[i]) {
_areas[i] = _ghost_area;
// normalise pt to be _ghost_area (NB we make use of fact that
// for initial particles, jet and clust_hist index are the same).
_area_4vectors[i] = (_ghost_area/_jets[i].perp()) * _jets[i];
} else {
_areas[i] = 0;
_area_4vectors[i] = PseudoJet(0.0,0.0,0.0,0.0);
}
}
// next follow the branching through and set up the areas
// and ghost-nature at each step of the clustering (rather than
// each jet).
for (unsigned i = _initial_n; i < _history.size(); i++) {
if (_history[i].parent2 == BeamJet) {
_is_pure_ghost[i] = _is_pure_ghost[_history[i].parent1];
_areas[i] = _areas[_history[i].parent1];
_area_4vectors[i] = _area_4vectors[_history[i].parent1];
} else {
_is_pure_ghost[i] = _is_pure_ghost[_history[i].parent1] &&
_is_pure_ghost[_history[i].parent2] ;
_areas[i] = _areas[_history[i].parent1] +
_areas[_history[i].parent2] ;
_jet_def.recombiner()->recombine(_area_4vectors[_history[i].parent1],
_area_4vectors[_history[i].parent2],
_area_4vectors[i]);
// _area_4vectors[i] = _area_4vectors[_history[i].parent1] +
// _area_4vectors[_history[i].parent2] ;
}
}
}
| double fastjet::ClustSeqActAreaEG::area | ( | const PseudoJet & | jet | ) | const [virtual] |
returns the area of a jet
Reimplemented from fastjet::ClusterSequenceAreaBase.
Definition at line 66 of file ClusterSequenceActiveAreaExplicitGhosts.cc.
References fastjet::PseudoJet::cluster_hist_index().
Referenced by fastjet::ClusterSequenceActiveArea::_transfer_areas().
{
return _areas[jet.cluster_hist_index()];
}
returns a four vector corresponding to the sum (E-scheme) of the ghost four-vectors composing the jet area, normalised such that for a small contiguous area the p_t of the extended_area jet is equal to area of the jet.
Reimplemented from fastjet::ClusterSequenceAreaBase.
Definition at line 80 of file ClusterSequenceActiveAreaExplicitGhosts.cc.
References fastjet::PseudoJet::cluster_hist_index().
Referenced by fastjet::ClusterSequenceActiveArea::_transfer_areas().
{
return _area_4vectors[jet.cluster_hist_index()];
}
| double fastjet::ClustSeqActAreaEG::empty_area | ( | const RangeDefinition & | range | ) | const [virtual] |
return the total area, up to |y|<maxrap, that consists of unclustered ghosts
Reimplemented from fastjet::ClusterSequenceAreaBase.
Definition at line 97 of file ClusterSequenceActiveAreaExplicitGhosts.cc.
References fastjet::RangeDefinition::is_in_range().
{
vector<PseudoJet> unclust = unclustered_particles();
double area = 0.0;
for (unsigned iu = 0; iu < unclust.size(); iu++) {
if (is_pure_ghost(unclust[iu]) && range.is_in_range(unclust[iu])) {
area += _ghost_area;
}
}
return area;
}
| bool fastjet::ClusterSequenceActiveAreaExplicitGhosts::has_dangerous_particles | ( | ) | const [inline] |
returns true if there are any particles whose transverse momentum if so low that there's a risk of the ghosts having modified the clustering sequence
Definition at line 124 of file ClusterSequenceActiveAreaExplicitGhosts.hh.
Referenced by fastjet::ClusterSequenceActiveArea::_run_AA(), and fastjet::ClusterSequenceActiveArea::_throw_unless_jets_have_same_perp_or_E().
{return _has_dangerous_particles;}
| virtual bool fastjet::ClusterSequenceActiveAreaExplicitGhosts::has_explicit_ghosts | ( | ) | const [inline, virtual] |
this class does have explicit ghosts
Reimplemented from fastjet::ClusterSequenceAreaBase.
Definition at line 108 of file ClusterSequenceActiveAreaExplicitGhosts.hh.
{return true;}
| bool fastjet::ClustSeqActAreaEG::is_pure_ghost | ( | int | history_index | ) | const |
true if the entry in the history index corresponds to a ghost; if hist_ix does not correspond to an actual particle (i.e.
hist_ix < 0), then the result is false.
Definition at line 91 of file ClusterSequenceActiveAreaExplicitGhosts.cc.
{
return hist_ix >= 0 ? _is_pure_ghost[hist_ix] : false;
}
| bool fastjet::ClustSeqActAreaEG::is_pure_ghost | ( | const PseudoJet & | jet | ) | const [virtual] |
true if a jet is made exclusively of ghosts
Reimplemented from fastjet::ClusterSequenceAreaBase.
Definition at line 85 of file ClusterSequenceActiveAreaExplicitGhosts.cc.
References fastjet::PseudoJet::cluster_hist_index().
Referenced by fastjet::ClusterSequenceActiveArea::_transfer_areas(), and fastjet::ClusterSequenceActiveArea::_transfer_ghost_free_history().
{
return _is_pure_ghost[jet.cluster_hist_index()];
}
| double fastjet::ClusterSequenceActiveAreaExplicitGhosts::max_ghost_perp2 | ( | ) | const [inline] |
returns the largest squared transverse momentum among all ghosts
Definition at line 119 of file ClusterSequenceActiveAreaExplicitGhosts.hh.
{return _max_ghost_perp2;}
| unsigned int fastjet::ClusterSequenceActiveAreaExplicitGhosts::n_hard_particles | ( | ) | const [inline] |
returns the number of hard particles (i.e. those supplied by the user).
Definition at line 217 of file ClusterSequenceActiveAreaExplicitGhosts.hh.
{return _initial_hard_n;}
| double fastjet::ClustSeqActAreaEG::total_area | ( | ) | const |
returns the total area under study
Definition at line 73 of file ClusterSequenceActiveAreaExplicitGhosts.cc.
{
return _n_ghosts * _ghost_area;
}
std::vector<PseudoJet> fastjet::ClusterSequenceActiveAreaExplicitGhosts::_area_4vectors [private] |
Definition at line 135 of file ClusterSequenceActiveAreaExplicitGhosts.hh.
std::vector<double> fastjet::ClusterSequenceActiveAreaExplicitGhosts::_areas [private] |
Definition at line 134 of file ClusterSequenceActiveAreaExplicitGhosts.hh.
double fastjet::ClusterSequenceActiveAreaExplicitGhosts::_ghost_area [private] |
Definition at line 132 of file ClusterSequenceActiveAreaExplicitGhosts.hh.
Definition at line 139 of file ClusterSequenceActiveAreaExplicitGhosts.hh.
unsigned int fastjet::ClusterSequenceActiveAreaExplicitGhosts::_initial_hard_n [private] |
Definition at line 146 of file ClusterSequenceActiveAreaExplicitGhosts.hh.
std::vector<bool> fastjet::ClusterSequenceActiveAreaExplicitGhosts::_is_pure_ghost [private] |
Definition at line 133 of file ClusterSequenceActiveAreaExplicitGhosts.hh.
double fastjet::ClusterSequenceActiveAreaExplicitGhosts::_max_ghost_perp2 [private] |
Definition at line 138 of file ClusterSequenceActiveAreaExplicitGhosts.hh.
get the area of the ghosts
Definition at line 131 of file ClusterSequenceActiveAreaExplicitGhosts.hh.
LimitedWarning fastjet::ClustSeqActAreaEG::_warnings [static, private] |
handle warning messages
allow for warnings
Reimplemented from fastjet::ClusterSequenceAreaBase.
Definition at line 140 of file ClusterSequenceActiveAreaExplicitGhosts.hh.
1.7.4
