the structure returned by the MassDropTagger transformer. More...
#include <fastjet/tools/MassDropTagger.hh>
Public Member Functions | |
| MassDropTaggerStructure (const PseudoJet &result_jet) | |
| ctor with initialisation More... | |
| double | mu () const |
| returns the mass-drop ratio, pieces[0].m()/jet.m(), for the splitting that triggered the mass-drop condition | |
| double | y () const |
| returns the value of y = (squared kt distance) / (squared mass) for the splitting that triggered the mass-drop condition | |
 Public Member Functions inherited from fastjet::WrappedStructure | |
| WrappedStructure (const SharedPtr< PseudoJetStructureBase > &to_be_shared) | |
| default ctor the argument is the structure we need to wrap | |
| virtual | ~WrappedStructure () |
| default (virtual) dtor | |
| virtual std::string | description () const |
| description | |
| virtual bool | has_associated_cluster_sequence () const |
| returns true if there is an associated ClusterSequence | |
| virtual const ClusterSequence * | associated_cluster_sequence () const |
| get a (const) pointer to the parent ClusterSequence (NULL if inexistent) | |
| virtual bool | has_valid_cluster_sequence () const |
| returns true if this PseudoJet has an associated and still valid ClusterSequence. More... | |
| virtual const ClusterSequence * | validated_cs () const |
| if the jet has a valid associated cluster sequence then return a pointer to it; otherwise throw an error | |
|
virtual const ClusterSequenceAreaBase * | validated_csab () const |
| if the jet has valid area information then return a pointer to the associated ClusterSequenceAreaBase object; otherwise throw an error | |
| virtual bool | has_partner (const PseudoJet &reference, PseudoJet &partner) const |
| check if it has been recombined with another PseudoJet in which case, return its partner through the argument. More... | |
| virtual bool | has_child (const PseudoJet &reference, PseudoJet &child) const |
| check if it has been recombined with another PseudoJet in which case, return its child through the argument. More... | |
| virtual bool | has_parents (const PseudoJet &reference, PseudoJet &parent1, PseudoJet &parent2) const |
| check if it is the product of a recombination, in which case return the 2 parents through the 'parent1' and 'parent2' arguments. More... | |
| virtual bool | object_in_jet (const PseudoJet &reference, const PseudoJet &jet) const |
| check if the reference PseudoJet is contained the second one passed as argument. More... | |
| virtual bool | has_constituents () const |
| return true if the structure supports constituents. More... | |
| virtual std::vector< PseudoJet > | constituents (const PseudoJet &reference) const |
| retrieve the constituents. More... | |
| virtual bool | has_exclusive_subjets () const |
| return true if the structure supports exclusive_subjets. | |
| virtual std::vector< PseudoJet > | exclusive_subjets (const PseudoJet &reference, const double &dcut) const |
| return a vector of all subjets of the current jet (in the sense of the exclusive algorithm) that would be obtained when running the algorithm with the given dcut. More... | |
| virtual int | n_exclusive_subjets (const PseudoJet &reference, const double &dcut) const |
| return the size of exclusive_subjets(...); still n ln n with same coefficient, but marginally more efficient than manually taking exclusive_subjets.size() More... | |
| virtual std::vector< PseudoJet > | exclusive_subjets_up_to (const PseudoJet &reference, int nsub) const |
| return the list of subjets obtained by unclustering the supplied jet down to n subjets (or all constituents if there are fewer than n). More... | |
| virtual double | exclusive_subdmerge (const PseudoJet &reference, int nsub) const |
| return the dij that was present in the merging nsub+1 -> nsub subjets inside this jet. More... | |
| virtual double | exclusive_subdmerge_max (const PseudoJet &reference, int nsub) const |
| return the maximum dij that occurred in the whole event at the stage that the nsub+1 -> nsub merge of subjets occurred inside this jet. More... | |
| virtual bool | has_pieces (const PseudoJet &reference) const |
| return true if the structure supports pieces. More... | |
| virtual std::vector< PseudoJet > | pieces (const PseudoJet &reference) const |
| retrieve the pieces building the jet. More... | |
| virtual bool | has_area () const |
| check if it has a defined area More... | |
| virtual double | area (const PseudoJet &reference) const |
| return the jet (scalar) area. More... | |
| virtual double | area_error (const PseudoJet &reference) const |
| return the error (uncertainty) associated with the determination of the area of this jet. More... | |
| virtual PseudoJet | area_4vector (const PseudoJet &reference) const |
| return the jet 4-vector area. More... | |
| virtual bool | is_pure_ghost (const PseudoJet &reference) const |
| true if this jet is made exclusively of ghosts. More... | |
| Public Member Functions inherited from fastjet::PseudoJetStructureBase | |
| PseudoJetStructureBase () | |
| default ctor | |
| virtual | ~PseudoJetStructureBase () |
| default (virtual) dtor | |
Protected Attributes | |
| double | _mu |
| the value of the mass-drop parameter | |
| double | _y |
| the value of the asymmetry parameter | |
| Protected Attributes inherited from fastjet::WrappedStructure | |
| SharedPtr< PseudoJetStructureBase > | _structure |
| the wrapped structure | |
Friends | |
| class | MassDropTagger |
the structure returned by the MassDropTagger transformer.
See the MassDropTagger class description for the details of what is inside this structure
Definition at line 123 of file MassDropTagger.hh.
|
inline |
ctor with initialisation
| pieces | the pieces of the created jet |
| rec | the recombiner from the underlying cluster sequence |
Definition at line 128 of file MassDropTagger.hh.
