fastjet 2.4.5
|
|
fastjet 2.4.5
|
Handle the computation of Voronoi jet area. More...
#include <ClusterSequenceVoronoiArea.hh>
Classes | |
| class | VoronoiAreaCalc |
| class for carrying out a voronoi area calculation on a set of initial vectors More... | |
Public Member Functions | |
| template<class L > | |
| ClusterSequenceVoronoiArea (const std::vector< L > &pseudojets, const JetDefinition &jet_def, const VoronoiAreaSpec &spec=VoronoiAreaSpec(), const bool &writeout_combinations=false) | |
| template ctor | |
| ~ClusterSequenceVoronoiArea () | |
| default dtor | |
| virtual double | area (const PseudoJet &jet) const |
| return the area associated with the given jet | |
| virtual PseudoJet | area_4vector (const PseudoJet &jet) const |
| return a 4-vector area associated with the given jet -- stricly this is not the exact 4-vector area, but rather an approximation made of sums of centres of all Voronoi cells in jet, each contributing with a normalisation equal to the area of the cell | |
| virtual double | area_error (const PseudoJet &jet) const |
| return the error of the area associated with the given jet (0 by definition for a voronoi area) | |
Private Member Functions | |
| void | _initializeVA () |
| initialisation of the Voronoi Area | |
Private Attributes | |
| std::vector< double > | _voronoi_area |
| vector containing the result | |
| std::vector< PseudoJet > | _voronoi_area_4vector |
| vector containing approx 4-vect areas | |
| VoronoiAreaCalc * | _pa_calc |
| area calculator | |
| double | _effective_Rfact |
| effective radius | |
Handle the computation of Voronoi jet area.
Definition at line 46 of file ClusterSequenceVoronoiArea.hh.
| fastjet::ClusterSequenceVoronoiArea::ClusterSequenceVoronoiArea | ( | const std::vector< L > & | pseudojets, |
| const JetDefinition & | jet_def, | ||
| const VoronoiAreaSpec & | spec = VoronoiAreaSpec(), |
||
| const bool & | writeout_combinations = false |
||
| ) |
template ctor
template constructor need to be specified in the header!
| pseudojet | list of jets (template type) |
| jet_def | jet definition |
| effective_Rfact | effective radius |
| writeout_combinations | ?????? |
Definition at line 99 of file ClusterSequenceVoronoiArea.hh.
: _effective_Rfact(spec.effective_Rfact()) { // transfer the initial jets (type L) into our own array _transfer_input_jets(pseudojets); // run the clustering _initialise_and_run(jet_def,writeout_combinations); // the jet clustering's already been done, now worry about areas... _initializeVA(); }
| fastjet::ClusterSequenceVoronoiArea::~ClusterSequenceVoronoiArea | ( | ) |
| void fastjet::ClusterSequenceVoronoiArea::_initializeVA | ( | ) | [private] |
initialisation of the Voronoi Area
Definition at line 271 of file ClusterSequenceVoronoiArea.cc.
{
// run the VAC on our original particles
_pa_calc = new VAC(_jets.begin(),
_jets.begin()+n_particles(),
_effective_Rfact*_jet_def.R());
// transfer the areas to our local structure
// -- first the initial ones
_voronoi_area.reserve(2*n_particles());
for (unsigned int i=0; i<n_particles(); i++) {
_voronoi_area.push_back(_pa_calc->area(i));
// make a stab at a 4-vector area
if (_jets[i].perp2() > 0) {
_voronoi_area_4vector.push_back((_pa_calc->area(i)/_jets[i].perp())
* _jets[i]);
} else {
// not sure what to do here -- just put zero (it won't be meaningful
// anyway)
_voronoi_area_4vector.push_back(PseudoJet(0.0,0.0,0.0,0.0));
}
}
// -- then the combined areas that arise from the clustering
for (unsigned int i = n_particles(); i < _history.size(); i++) {
double area;
PseudoJet area_4vect;
if (_history[i].parent2 >= 0) {
area = _voronoi_area[_history[i].parent1] +
_voronoi_area[_history[i].parent2];
area_4vect = _voronoi_area_4vector[_history[i].parent1] +
_voronoi_area_4vector[_history[i].parent2];
} else {
area = _voronoi_area[_history[i].parent1];
area_4vect = _voronoi_area_4vector[_history[i].parent1];
}
_voronoi_area.push_back(area);
_voronoi_area_4vector.push_back(area_4vect);
}
}
| virtual double fastjet::ClusterSequenceVoronoiArea::area | ( | const PseudoJet & | jet | ) | const [inline, virtual] |
return the area associated with the given jet
Reimplemented from fastjet::ClusterSequenceAreaBase.
Definition at line 63 of file ClusterSequenceVoronoiArea.hh.
References fastjet::PseudoJet::cluster_hist_index().
Referenced by fastjet::ClusterSequencePassiveArea::_initialise_and_run_PA().
{
return _voronoi_area[jet.cluster_hist_index()];};
| virtual PseudoJet fastjet::ClusterSequenceVoronoiArea::area_4vector | ( | const PseudoJet & | jet | ) | const [inline, virtual] |
return a 4-vector area associated with the given jet -- stricly this is not the exact 4-vector area, but rather an approximation made of sums of centres of all Voronoi cells in jet, each contributing with a normalisation equal to the area of the cell
Reimplemented from fastjet::ClusterSequenceAreaBase.
Definition at line 70 of file ClusterSequenceVoronoiArea.hh.
References fastjet::PseudoJet::cluster_hist_index().
Referenced by fastjet::ClusterSequencePassiveArea::_initialise_and_run_PA().
{
return _voronoi_area_4vector[jet.cluster_hist_index()];};
| virtual double fastjet::ClusterSequenceVoronoiArea::area_error | ( | const PseudoJet & | jet | ) | const [inline, virtual] |
return the error of the area associated with the given jet (0 by definition for a voronoi area)
Reimplemented from fastjet::ClusterSequenceAreaBase.
Definition at line 75 of file ClusterSequenceVoronoiArea.hh.
{
return 0.0;};
double fastjet::ClusterSequenceVoronoiArea::_effective_Rfact [private] |
effective radius
Definition at line 90 of file ClusterSequenceVoronoiArea.hh.
area calculator
Definition at line 89 of file ClusterSequenceVoronoiArea.hh.
std::vector<double> fastjet::ClusterSequenceVoronoiArea::_voronoi_area [private] |
vector containing the result
Definition at line 87 of file ClusterSequenceVoronoiArea.hh.
std::vector<PseudoJet> fastjet::ClusterSequenceVoronoiArea::_voronoi_area_4vector [private] |
vector containing approx 4-vect areas
Definition at line 88 of file ClusterSequenceVoronoiArea.hh.
